SINOTRUK 18T 3m³ Compact Wheel Loader ZL50G highly cost effective

Name: SINOTRUK 18T 3m Compact Wheel Loader ZL50G highly cost effective
Brand: CIVL
Price: 1 USD

Place of Origin : China

Brand Name : CIVL

Model Number : CIVL

MOQ : 1

Price : Negotiable

Packaging Details : Nude

Delivery Time : Within 35 days

Payment Terms : T/T, L/C

Supply Ability : 100 units per week

Certification : ISO,CCC

Contact Now

18T 3m³ Compact Wheel Loader ZL50G , Yellow Small Wheel Loader

SINOTRUK 18T 3m³ Compact Wheel Loader ZL50G highly cost effective

Description:

1.Heavy load for the rocky condition; the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity.
2.The large rock bucket with capacity of 3.0m³ is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of tooth holder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.
3.The thickness of the front frame lug and baseboard is 70mm, and the thickness of the up and down articulated board is 30mm. The machine is superior among the products of same kind in terms of the structural strength and carrying capacity.

Specifications:

Bucket	ZL50G
Bucket capacity	3.0M³
Rated load	5000kg
Rated time	6 secretary
Total cycling time	11secretary
Max.drawing force	145Kn
Max.breakout force	170Kn
Articulation angle	35^.
Min.turn radius	6400mm
Climb ability	28^.
Wheel base	3300mm
Tread	2200mm
Dumping clearance	3090mm
Dumping reach	1130mm
L×W×H	8110×3000×3508mm
Operating weight	18t
Clamp type
Min.clamping diameter	φ450/φ800mm
Dumping clearance	3230mm
Dumping reach	1845mm
L×W×H	8414×2800×3460mm
Operating weight	18t

International Market:Ethiopia/Africa/Uganda/Chad/Zambia/Tanzania/Liberia/Myanmar
/Cambodia/Thailand/Malaysia

Other Truck can be provide according to your request, freely contact me for the informations and quotations.
