| name | Self suction direct high speed centrifugal pump |
| Model | QGZ25-30A |
| Pump | Inlet diameter(mm) | 25 |
| The diameter of the outlet (mm) | 25 |
| flow(m³/h) | 8 |
| Lift(m) | 30 |
| Suction lift(m) | 8 |
| Engine | Model | 1E36F-2A |
| Power(kw/r/min) | 0.9/6500 |
| Displacement(cc) | 32.6 |
| Package | Power(kg) | 7.5 |
| Package Size(mm) | 400×330×390 |
| Name | Self suction direct high speed centrifugal pump |
| Model | QGZ40-35E |
| pump | Inlet diameter(mm) | 40 |
| The diameter of the outlet(mm) | 40 |
| Flow(m³/h) | 15 |
| lift(m) | 35 |
| Suction lift(m) | 8 |
| Engine | Model | 1E40F-2E |
| power(kw/r/min) | 1.1/6500 |
| Displacement(cc) | 42.7 |
| Package | Net Weight(kg) | 11 |
| Package Size(mm) | 400×330×490 |
| Model | 50ZB30-3.2Q |
| Mating power | 168F |
| The diameter of the outlet(mm) | 50 |
| Flow(m³/h) | 35 |
| Suction lift(m) | 8 |
| MaxLift(m) | 30 |
| Weight(kg)(kg) | 22 |
| Package Size(mm) | 500×387×430 |
| Model | 80ZB20-4.0C |
| Mating power | C178F |
| The diameter of the outlet(mm) | 80 |
| Flow(m³/h) | 50 |
| Suction lift(m) | 8 |
| Maxlift(m) | 20 |
| Weight(kg) | 47 |
| External Dimension(mm) | 600×490×570 |
| Three cylinder pump |
| Model | Mating power | Pressure(Mpa) | Flow(m³/h) | Range(m) | power(kw/r/min) | Net weight(kg) | Package Dimension(mm) |
| 3WZ-30 | FujiEX17 | 1.5-3.5 | 30 | 18 | 2.94/3600 | 28 | 1600×340×440 |
| Model | ZB100 |
| Flow(cbm) | 96 |
| Suction Length(m) | 8 |
| Lift(m) | 16 |
| Discharge(ml) | 270 |
| Net Weight(Kg) | 50 |
| Power | 177F |
| Water Outlet Diameter(mm) | 100 |
| Package Size(mm) | 640*500*580mm |
- performance characteristics and applicable scope: this kind of pump belongs to the ground drainage and irrigation machinery, and has the characteristics of small volume, light weight, compact structure, convenient operation;
Can be widely used in farmland, garden irrigation, domestic water, as well as construction, industrial and mining enterprises to the water supply and drainage, etc..
Extraordinary power, fashionable design, beautiful and of lower vibration, lower noise and higher lift and strong suction.
The water pump has gained CE certificates.
Optimization of the design of the spiral and the impeller, reduce the Sheung Shui time, strong power output and high lift.
This kind of pump belongs to the ground drainage and irrigation machinery, and has the characteristics of small volume, light weight, compact structure, convenient operation; can be widely used in farmland, garden irrigation, domestic water, as well as the construction, industrial and mining enterprises drainage.
