Hot sale!!!WB18 Soil Stabilizer with 1800mm Mixing Width road machinery
Specifications
XCMG Cheap Soil Stabilizer For Road WB18
1.Milling width 1800mm
2.Max.mixed depth 400mm
3.Engine power 310kw
Description:
The soil stabilizer WB18 is a special road construction machinery .It can be app lied to mixing
foundation materials on the spot in constructions of highways,airports and city buildings.
The soil stabilizer WB18 is a special road construction machinery .It can be app lied to mixing
foundation materials on the spot in constructions of highways,airports and city buildings.
Main Features of Soil stabilizer
1. Powerful and reliable CUMMINS NTA855-C360 engine.
2. Mixing and traveling systems are full hydraulic transmission.lnfinitely variable travel speed
control is achieved.The working is stable and reliable .Hydraulic parts are world famous products.
The function of APA[Automatic Power Allot]makes the overload protection an high impact
resistance achieved .These insure a long life-span of the machine .
3. Front wheel steering, lifting of rotor arm ,open and close of rotor hood tail gate are all hydraulic
controlled .
4. With a large contact area,low pressure tyres which are special.Used for construction machinery
increase
tractive power of the machine effectively.
5. The driver ' s cab is well insulated by using double-layer structure and also equipped with
cooling&heating dual function air conditioner.Operating in the driver" s cad is safe and
comfortable.
The machine is also equipped with falling objects protective device and ant i- rolling device.
Main parameters of WB18 Soil stabilizer
| Model | WB18 |
| Engine Type | NTA855-c400 |
| Engine output/speed (kW/hp) | 258/400 |
| Rated speed (r/min) | 2000 |
| Max Drum speed (r/min) | 135 |
| Milling and mixing rotor operating width (mm) | 2300 |
| Milling and mixing rotor operating depth(mm) | 400 |
| Milling and mixing rotor blade ( piece ) | 160 |
| Operation rotor rotation direction | Reverse |
| Max. Speed(km/h) | 24 |
| Working speed (km/h) | 0-3.3 |
| Minimum turning radius (mm) | 7500 |
| Approach angle (°) | 19 |
| Departure angle (°) | 16.5 |
| Min. ground clearance (mm) | 380 |
| Tires (front/rear) | 2*2 |
| Dimensions(L*W*H)(mm) | 8530*3128*3500 |
Tag:soil stabilizer, soil mixing machine,road machine.
